Description Offshore Weather Sensor | EOLOS-Nav2 Id-No. 00.16432.210002 Meas. range wind direction 0…360° Meas. range wind speed 0.1…85 m/s Meas. range air temperature -40… 70 °C Meas. range rel. humidity 0…100 % r. h. Meas. range barometric pressure 600…1100 hPa Accuracy wind direction ± 3° Accuracy wind speed ± 0.5 m/s ± 5 % of the meas. value Accuracy air temperature ± 0.8 °C (v > 2 m/s) Accuracy rel. humidity ± 3 % (10…90 %) ± 4 % (0…100 %) Accuracy barometric pressure ± 2 hPa (-40… 85 °C) ± 0.5 hPa at 25 °C Resolution wind direction 1° Resolution wind speed 0.1 m/s Resolution air temperature 0.1 °C Resolution rel. humidity 0.5 % r. h. Resolution barometric pressure 0.1 hPa Protocols NMEA 0183 WIMWV WIMHU WIMMB WIMTA Interface serial RS 422/ talker baud rate 4800 1 Hz (meas. cycle of 4 Hz) 8N1 Update rate 4 Hz Range of application temperature -40… 70 °C wind speed 0…100 m/s humidity 0…100 % r.h. Supply voltage 18…32 V DC · max. 2.5 A heating: 24 V DC/ 70 W (max. 3 A) · electr. controlled Dimensions H 388 mm Ø 120 mm mast adapter Ø 50 mm for mounting on standard pipe Housing aluminium anodised IP 66 Weight approx. 2.5 kg Options (order separately) Indicator unit e.g. (14742) METEO-LCD/NAV Data logger e.g. SYNMET-NAV or met[LOG] Mast and power supply unit Visualisation and evaluation software MeteoWare-CS3 Accessories (order separately) 32.16420.066100 Cable 10 m 12-pole bayonet plug ready-made Offshore Weather Sensor | EOLOS-Nav2
